UNBOXING OF HMT MAKE SLANT BED COMPUTER NUMERIC CONTROL MACHINE || SBCNC 60

Описание

Designed for high speed turning of components, with high rigidity and minimum torsional deflection. » The single machine for multiple benefits. » Optional Turn Mill Center with C-axis and driven tools. » Optional Flexible Turning Cell with gantry job/tool loading/unloading and post processor. » 70° Inclined computer optimised slant bed with large torque tube. » Separate pairs of hardened and ground rectangular guideways for saddle and tailstock. » Main spindle supported on Gamet preloaded taper roller bearings. » Large precision curvic couplings ensure accuracy of turret indexing and high rigidity of turret. Specifications : SBCNC 40 SBCNC 60 Swing over bed mm 660 800 Maximum turning dia. mm 400 600 Maximum turning length mm 1250/2000/3000 1250/2000/3000 Maximum chuck dia. mm 500 600 Bar passage mm 103 (210 optional) 103 (210 optional) Spindle power kW 22 (up to 60) 22 (up to 60) Speed range rpm 12-2800 12-2000 Rapid traverse m/min 10 10 No. of tool stations m/min 12 12 Tailstock quill travel mm 125 / 160 125 / 160 Control system Siemens / Fanuc Siemens / Fanuc Maximum weight carrying capacity Maximum turning length mm 1000 1000 Maximum chuck dia. mm 1500 1500 Bar passage mm 500 500
